Shield Series — Deadbolt + Entry Lever

Product Details

• Material

  Zinc-alloy entry lever and latch with a 304 stainless steel rosette, brass keys, and a steel deadbolt body and hardware. Glossy, lacquer-coated finish, built to keep its color.
• Door Compatibility

  Fits standard US interior doors 1-3/8" to 1-3/4" thick. The latch adjusts to both 2-3/8" (60mm) and 2-3/4" (70mm) backsets, and works with a standard 2-1/8" bore.
• Installation Requirements

  Installs in about an hour on standard pre-drilled doors with a Phillips screwdriver. The entry set and deadbolt arrive keyed alike, so one key works both. Adjustable 2-3/8"/2-3/4" backset, with illustrated guides for both pieces in the box.
• What's Included

  A keyed entry lever, a single-cylinder deadbolt, both latches, strike plates, mounting screws, 4 keys (lever and deadbolt keyed alike), and illustrated installation guides for both pieces.
• Dimensions & Weight

  Packaged set weighs about 1.1 kg (2.43 lb). Retail box: 180 x 160 x 80 mm.
• Warranty

  1-year finish warranty and 3-year mechanical warranty.
• Certifications

  ANSI/BHMA Grade 3.
