Sentinel Lever — Passage

Product Details

• Material

  Zinc-alloy lever and latch with a 304 stainless steel rosette, on steel mounting hardware. Glossy, lacquer-coated finish, built to keep its color.
• Door Compatibility

  Fits standard US interior doors 1-3/8" to 1-3/4" thick. The latch adjusts to both 2-3/8" (60mm) and 2-3/4" (70mm) backsets, and works with a standard 2-1/8" bore.
• Installation Requirements

  Installs in under 30 minutes on a pre-drilled door with just a Phillips screwdriver. Switch the backset by pulling out or pushing in the rear of the latch — no tools needed. An illustrated template is included in the box.
• What's Included

  Interior and exterior levers, a passage latch, strike plate, mounting screws, and an illustrated installation guide. Passage levers are non-locking — perfect for hallways, closets, and pantry doors.
• Dimensions & Weight

  Packaged set weighs about 0.81 kg (1.79 lb). Retail box: 175 x 148 x 80 mm.
• Warranty

  1-year finish warranty and 3-year mechanical warranty.
• Certifications

  ANSI/BHMA Grade 3.
